| UVW (Unloaded Vehicle Weight)* | 8,660 |
| Dry Hitch Weight* | 1,070 |
| Dry Axle Weight* | 7,590 |
| NCC (Net Carrying Capacity) | 1,335 |
| GVWR | 9,995 |
| Interior Height | 82" |
| Exterior Height with A/C | 11' 4" |
| Exterior Width | 96" |
| Exterior Length | 37' 11" |
| Refrigerator (Cubic Feet) | 8 |
| Water Heater Cap. (Gal. G/E w/DSI) | 6 |
| Fresh Water Cap. (Gal.) | 40 |
| Black Water Cap. (Gal.) | 64 |
| Gray Water Cap. (Gal.) | 64 |
| LP Gas Cap. (Lbs.) | 60 |
| Furnace BTUs (1,000s) | 30 |
| Tire Size | 15" |
| Awning | 20' |
*This weight reflects the rolling average unit weight for each model. Your trailer weight will vary according to optional equipment. |
|
